Focmag 3102 Electromagnetic Flow Meter

No.Focmag3102
Place of Origin
Jiangsu, China
Warranty
12months
Customized support
OEM, ODM, OBM
Brand Name
Hua Hai
Model Number
Focmag3102
Product Name
Electromagnetic Flow Meter
Medium
Conductive Liquid
Power supply
220VAC、24VDC
Material
Carbon Steel/ SS304/SS316L/etc
Output
4-20mA /RS485/HART
Display
LCD /OLED display
Size
DN10~DN1800
Pressure
0.6Mpa/ 1.0Mpa/ 1.6Mpa / 2.5 Mpa / 4.0 Mpa/ 6.3Mpa/ 10 Mpa/ 16Mpa
Accuracy
0.5%/1.0%
Protection Class
IP65/ IP68(optional)
  • Focmag 3102 Electromagnetic Flow Meter
  • Focmag 3102 Electromagnetic Flow Meter
  • Focmag 3102 Electromagnetic Flow Meter
  • Focmag 3102 Electromagnetic Flow Meter
Description
Electromagnetic flowmeters are devices designed to measure the volumetric flow of conductive liquids and slurries in sealed pipelines. These flowmeters operate based on Faraday's law of electromagnetic induction, which states that a voltage is induced when a conductive fluid moves through a magnetic field. The induced voltage is directly proportional to the velocity of the fluid, allowing the flowmeter to accurately measure the flow rate.

Features:

  1. Simple Structure and Reliability: These flowmeters have no moving parts and a long service life, ensuring reliable performance.
  2. No Flow Obstruction: With no parts intercepting the fluid, there is no pressure loss or fluid clogging.
  3. Quick Response and Stability: Lacking mechanical inertia, they respond quickly and maintain good stability, suitable for automatic examination, regulation, and control systems.
  4. Measurement Accuracy: The accuracy is unaffected by physical parameters such as fluid type, temperature, viscosity, density, and pressure.
  5. Enhanced Sealing: Individually designed sealing parts prevent external moisture from entering the converter and sensor at their junction.
  6. High-Quality Coils: The excitation coil uses high-quality single-core shielding wire to reduce interference and improve signal cleanliness, enhancing measurement accuracy.
  7. Durable Coating: The sensor surface is painted with metal fluorocarbon paint, offering excellent durability, resistance to ultraviolet light, and weather resistance, minimizing maintenance needs.
  8. Bidirectional Measurement: Capable of bidirectional flow measurement and total accumulation, with three totalizers for forward, reverse, and difference value accumulation.
  9. Low-Frequency Excitation: Programmable into low-frequency three-value wave excitation, improving stability and reducing power loss.
  10. Advanced Processing: Utilizes a new 32-bit ARM+CPLD for high integration, fast operation, and high calculation accuracy.
  11. Digital Processing: Full digital processing ensures strong anti-interference ability and reliable measurement.
  12. Low EMI Power Supply: Ultra-low EMI switching power supply accommodates a wide range of voltage changes, offering high efficiency, low temperature rise, and good EMC performance.
  13. User-Friendly Interface: Chinese and English menu operation, easy to use, simple to operate, and easy to learn.
  14. High-Resolution Display: High resolution and wide temperature range OLED display.
  15. Intelligent Judgments: Simplifies operation by eliminating the need for measurement correction settings, with convenient empty pipe alarm and electrode detection applications.
  16. Error Processing: Advanced "Gross Error Processing" technology removes slurry and other fluid measurement cusp interference, reducing output fluctuations and maintaining high precision.
  17. Self-Check and Diagnosis: Built-in self-check and self-diagnosis functions.
  18. Improved Keyboard Handling: New keyboard design prevents operation from affecting measurement, making parameter settings more convenient.
  19. Stable Current Output: Uses AD421 current dedicated chip for a more stable 4-20mA current output.
